The carbon fiber lightest gravel frame redefines off-road agility, merging extreme lightness with rugged trail capability. Forged from ultra-high-modulus T1100 carbon fiber, it tips the scales at just ~1150g (frame only)-30% lighter than standard gravel frames-without sacrificing structural integrity.
Its optimized monocoque construction delivers stiff power transfer for climbs, while compliance-tuned seatstays absorb jarring gravel impacts. With max 700×47mm tire clearance, it grips loose terrain effortlessly, while aerodynamic truncated tube shapes cut drag on paved connectors.
Thru-axles and flat-mount disc brake compatibility boost stability, even on technical descents. Whether tackling backcountry gravel, forest trails, or mixed-terrain epics, this frame turns every pedal stroke into forward momentum-proving lightness and durability can coexist.
UCI Approved: Yes
Including Parts: MG-021 Frame, Fork, Handlebar, Seatpost
Carbon Fiber Lightest Gravel Frame Specification:
Size: 45cm,49cm, 52cm, 54cm, 56cm, 58cm, 60cm
Material: High Modulus Toray 800 Carbon Fiber
Color: Arctic Ice / Desert Brown / Custom Painting
BB: T47 inboard bearing (pick the right BB-47 depending on your crank spindle size)
E.g. if you are using crank : T47 BB inboard bearing for (shimano) 24mm spindle size.
SRAM DUB / DUB wide crank : T47 BB inboard bearing for SRAM DUB
SRAM GXP : T47 BB Inboard bearing for SRAM GXP
Headtube: Straight 1-1/2"
Rear Dropout: 12*142 Thru Axle
Rear Derailleur Hanger: Replaceable
Frame Weight:
Arctic Ice 1150g (49cm) +/-50g
Desert Brown 1170g (49cm) +/-50g
Raw 1050g (49cm) +/-50g
Handlebar: H21 carbon integrated handlebar
Handlebar Size: 400mm,420mm,440mm
Stem Size: 80mm/90mm/100mm/110mm
Handlebar Weight: 360+/-15g (420x90)
Fork & Seatpost:
Fork: 1 1/8" - 1 1/2", 12*100 Thru Axle
Fork Weight:
G21 Fork : 475+/-10(with holes)
G21 Fork: 465+/-10(without holes)
Seatpost Weight: 204+/-15g
Compatibility:
Chainring:
Single (Max of 42t for normal crank spindle and 44t for wide crank spindle)
Double (50-34t max with BB to Crank washer)
Brake Fitment: Flat Mount Disc
Cable Routing: Internal
Bottle Mounts : 4
Mudguard Compatible: Yes
Cargo Rack Compatible: Yes
Max Tire Width: 700X53mm , 650BX2.1"
Accessories:
Handlebar Spacers 3mm: 1PC, 5mm: 1PC, 10mm: 2PCS, Headset Bearing Cap 10mm:1PC
Front Axle: 1pc, Rear Axle: 1pc
Limited Rider Weight: 110KG
Warranty: 6 Years
